2N5401 is a PNP transistor designed specifically for high voltage - low power switching applications and amplifications. The NPN complementary for the device is 2N5551 and is available in TO-92, SOT54.

Pin Configuration

2N5401 has three pins like any other transistor namely EMITTER, BASE and COLLECTOR.

Pin	Name	Function
1	Emitter	Current flows in to the device through this pin
2	Base	Base is used for triggering transistor ON and OFF
3	Collector	Current flows out of this pin

2N5401 Features and Electrical characteristics

Available in Pb−Free package
High collector breakdown voltage
With DC Current Gain (hFE) up to 100
Maximum voltage across collector and emitter: 150V
Maximum current allowed trough collector: 600mA
Maximum voltage across collector and base: 160 V
Maximum voltage across base and emitter: 5V
Operating temperature range: -55ºC to +150ºC
Maximum power dissipation : 0.62 W

Similar Transistors

2N5551 (NPN), MPSA92, MPSA93, BF723, 2N5096

2N5401 Transistor Overview

2N5401 is specifically designed to be used in high voltage applications where load consumes very less power (i.e. Current drawn by load is low). These types of circuits can be seen in telephone systems. It can also be used when you want a simple switching device for high voltage loads. Also the component is cheap and easy to work with.

How to Use 2N5401 Transistor?

2N5401 can be used like any general purpose PNP transistor but for sake of understanding the device working let us consider a simple application circuit as shown below.

In the above circuit we are using 2N5401 as a simple switching device and the switching load being small DC motor. The button here is for providing the trigger to the transistor and 10KΩ resistor is for limiting the current to base and to avoid breaching maximum voltage allowed at the base. The circuit is powered from a negative voltage source of -5V DC as shown in diagram.

Before going for working let us revise the typical characteristics of a PNP transistor:

The device does not conduct when the current does not flow out of the base of the transistor or the device conducts only when the base current that flows out of the device reaches a threshold.
The current flow through collector is determined by the base current to a certain point. So with higher the gate current we have lower conduction resistance and higher the collector current.
The PNP transistor conducts only when a threshold current flows out the base, so the instant the base current reaches zero the device stops conducting.

Consider the button is not pressed: When the button is not pressed there will be no base current and with no base current the transistor will not conduct based on the characteristics of PNP transistor. When the transistor does not conduct the entire voltage appears across it and the motor will be OFF.

Consider the button is pressed: When the button is pressed, the base of 2N5401 will be connected to negative power supply and so there will be a path for the current flow. When the base current flows out from the device it will start conducting as stated in characteristics. In the presence of this collector current flow a voltage appears across the motor connected in series with collector pin. In the presence of the voltage the motor will start rotating and it will stay like that until the button is released. The moment the button is released the base current will reaches zero, there by turning OFF the transistor and the motor.

In this way we can turn motor ON and OFF by using simple button as a trigger and 2N5401 as switching device. In high speed switching the trigger is provided by microcontroller instead of button.

Data Persamaan Transistor

Applications

General purpose switching and amplification
Telephony applications
High voltage application
